Gas Lens Cup Long 1/2" 54N14L Binzel
SKU:
10075062
The Abicor Binzel 54N14L #8 Long Alumina Ceramic TIG Gas Lens Cup is a professional welding consumable designed for extended-reach TIG applications using standard gas lens configurations. Its elongated 76mm profile and 12.5-13mm bore provide improved access to narrow, recessed and difficult-to-reach joints while maintaining effective shielding gas coverage. Manufactured from high-grade alumina ceramic, it offers excellent thermal resistance and is compatible with standard 17, 18 and 26 Series TIG torch systems.
Features & Benefits
» Genuine Abicor Binzel long-profile TIG gas lens ceramic cup
» #8 Long configuration provides a 12.5-13mm (1/2") shielding gas orifice
» Extended 76mm profile provides improved access to deep and restricted welding joints
» Designed for standard and regular gas lens TIG torch configurations
» Supports stable, laminar shielding gas flow for effective weld pool protection
» Allows extended tungsten stickout while maintaining excellent joint visibility
» High-grade alumina ceramic construction provides excellent thermal resistance
» Ideal for tube clusters, pipe roots, inside corners and other recessed applications
» Compatible with standard 17, 18 and 26 Series TIG welding torches
» Suitable for demanding professional TIG welding and fabrication applications
Technical Specifications
» Brand: Abicor Binzel
» Product Name: Long Alumina Ceramic TIG Gas Lens Cup
» Part Number: 54N14L
» Manufacturer Part Number: BIN54N14L
» Product Type: Long TIG Gas Lens Cup
» Cup Size: #8 Long (#8L)
» Orifice Diameter: 12.5-13mm (1/2")
» Material: Alumina Ceramic (Aluminium Oxide)
» Colour: Pink
» Overall Length: 76mm (3")
» Outer Base Thread Diameter: Approximately 19mm
» Compatible Torch Series: 17, 18 And 26 Series
» Compatible Air-Cooled Torches: WP-17, WP-26, ABITIG GRIP 17 And ABITIG GRIP 26
» Compatible Liquid-Cooled Torches: WP-18 And ABITIG GRIP 18
» Compatible Gas Lens Bodies: 45V24, 45V26 And 45V27
» Required Insulator: 54N63 Gas Lens Insulator
» Recommended Applications: Deep Joints, Tube Clusters, Pipe Roots And Inside Corners
» Weight: Approximately 15g
