Camlock 6" Part E Alloy .
SKU:
10014405
The Snaplock 6" Aluminium Part E Camlock Adaptor is a heavy-duty quick-connect fitting designed for high-volume fluid transfer applications. Featuring a 6" male Camlock adaptor with an integrated 6" hose tail, it provides a secure, tool-free connection for large-bore suction and discharge hoses used in dewatering, wastewater management, agriculture and industrial fluid handling.
Features & Benefits
» Part E Camlock adaptor with male Camlock plug and hose tail connection
» Manufactured from high-strength T6 heat-treated aluminium alloy for excellent durability and reduced weight
» Multi-serrated hose tail provides a secure grip inside large-bore flexible hoses
» Tool-free connection and disconnection with compatible female Camlock couplers
» Manufactured to EN 14420-7 and A-A-59326 (formerly MIL-C-27487) standards for full interchangeability
» Lightweight aluminium construction reduces hose sag and eases installation
» Suitable for heavy-duty rubber, PVC layflat and suction/discharge hoses
» Ideal for dewatering, wastewater bypass, slurry transfer, irrigation, tanker operations and industrial fluid handling
Technical Specifications
» Brand: Snaplock
» Product Type: Part E Camlock Adaptor
» Part Number: E600-A / E6-AU
» Nominal Size: 6" (DN150)
» Camlock Type: Part E
» Camlock Connection: 6" Male Camlock Plug
» Hose Connection: 6" Hose Tail (Approx. 152.4mm OD)
» Camlock Standard: EN 14420-7 / A-A-59326 (Formerly MIL-C-27487)
» Connection Method: Tool-Free Quick Connect
» Body Material: T6 Heat-Treated High-Strength Aluminium Alloy
» Gasket: Not Required On Male Adaptor (Seal Located In Mating Female Coupler)
» Maximum Working Pressure: 5 Bar (72.5 PSI)
» Operating Temperature: -40°C To +100°C
» Suitable Hose Types: Heavy-Duty Rubber, PVC Layflat And Suction/Discharge Hose
» Suitable Media: Water, Wastewater, Oils, Fuels, Slurry, Powders, Granules And Non-Corrosive Industrial Liquids
» Not Suitable For: Compressed Air, Steam Or Gas Applications
» Typical Applications: Construction Dewatering, Municipal Water Bypass, Agricultural Slurry Transfer, Irrigation, Tanker Operations And Industrial Fluid Transfer
