Tig Rod A38 3.2mm x 5Kg UTP
SKU:
10104952
The Böhler Welding UTP A38 3.2mm Copper TIG Welding Rod is a solid copper filler rod designed for TIG welding and surfacing oxygen-free and deoxidised copper materials. Supplied in a 5kg pack of 1000mm rods, it provides good electrical conductivity and controlled weld pool characteristics for demanding copper fabrication and repair applications.
In Stock
Typical Lead Time: 36 Days
Features & Benefits
» Solid copper TIG welding rod designed for fusion welding and surfacing compatible copper materials
» Suitable for oxygen-free and deoxidised copper grades including OF-Cu, SE-Cu, SW-Cu and SF-Cu
» 3.2mm rod diameter provides increased filler deposition for thicker copper sections and heavy-duty fabrication
» Produces a controlled, viscous weld pool to support consistent deposition during copper welding
» Provides good electrical conductivity for applications involving conductive copper components
» Suitable for fabrication and repair of conductor rails, busbars, electrical connections and other copper components
» Supplied in standard 1000mm cut lengths for professional TIG welding applications
» Designed for use with 100% Argon, Argon/Helium or Helium shielding gas depending on the welding application and material thickness
» Suitable for industrial fabrication, electrical engineering, power generation and general copper repair work
Technical Specifications
» Brand: Böhler Welding
» Product Range: UTP
» Product Grade: UTP A38
» Product Reference: UTP38
» Product Type: Copper TIG Welding Rod
» Material Type: Solid Copper
» Welding Process: GTAW / TIG
» Rod Diameter: 3.2mm
» Rod Length: 1000mm
» Pack Weight: 5kg
» Compatible Base Materials: OF-Cu, SE-Cu, SW-Cu And SF-Cu
» Electrical Conductivity: Approximately 30–45 S·m/mm²
» Melting Range: Approximately 1070°C To 1080°C
» Recommended Shielding Gas: 100% Argon, Argon/Helium Or Helium
