Hose Tail Hex 1/2" BSPT x 3/4" Stainless
SKU:
10092362
The SJ-F29-0812 Hose Tail Adaptor is a reducing brass fitting designed to connect smaller BSP threaded ports to larger flexible hose systems. It highlights a tapered BSPT male thread for secure sealing, a robust 3/4in hose barb connection, and reliable performance in industrial fluid transfer applications.
Features & Benefits
» Reducing hose tail adaptor designed to connect smaller threaded ports to larger flexible hose systems
» 1/2in BSPT male tapered thread provides a secure and leak-resistant mechanical seal
» 3/4in hose barb designed to suit 3/4in (19mm) internal diameter flexible hose
» Step-up hose configuration allows connection from a 1/2in threaded outlet to a larger 3/4in hose line
» Suitable for fluid transfer, pneumatic, irrigation, and industrial hose applications
» Hose barb profile provides secure hose retention when used with suitable hose clamps
» PTFE tape or pipe jointing compound is recommended for leak-free installation
» Compatible with BSP threaded ports including BSPT and BSPP female connections
» Slight flow restriction may occur due to the smaller threaded inlet size
» Stainless steel worm-drive hose clamps are recommended for secure hose installation
» Robust fitting design supports dependable performance in workshop, agricultural, and industrial environments
» Not compatible with American NPT threaded systems
Technical Specifications
» Product Type: Hosetail Adaptor
» Part Number: SJ-F29-0812
» Connection A: 1/2 in Male BSPT (British Standard Pipe Taper)
» Connection B: 3/4 in Hose Barb
» Hose Compatibility: 3/4 in / 19 mm Internal Diameter Hose
» Thread Type: BSPT Tapered Male Thread
» Configuration: Step Up Hose Tail Adaptor
» Construction: Straight Hose Tail Adaptor Design
» Sealing Method: Tapered Thread Provides Leak Proof Mechanical Seal
» Installation Requirement: Apply PTFE Tape Or Pipe Jointing Compound To BSPT Threads
» Hose Securing Method: Use Stainless Steel Worm Drive Hose Clamp
» Recommended Clamp Size: 22 – 30 mm
» Flow Characteristic: Potential Flow Restriction Due To Reduced 1/2 in Threaded Port
» Thread Compatibility: Suitable For BSPT And BSPP Female Ports
» Thread Restriction: Not Compatible With NPT Threads
» Application: Fluid Transfer And Pneumatic Systems
» Suitable Use: Industrial, Commercial And Workshop Installations
