Tig Rod PZ6500 A18 2.4mm x 5Kg Filarc
SKU:
10024129
The ESAB Filarc PZ6500 A18 TIG Welding Rods are copper-coated carbon-manganese steel filler rods designed for TIG welding mild and medium-strength steels. Classified as ER70S-6 / W3Si1 and supplied as 2.4mm x 1000mm rods in a 5kg pack, their manganese and silicon deoxidisers support clean, consistent weld deposits and good mechanical properties.
Features & Benefits
» Carbon-manganese steel TIG filler rods designed for welding mild and medium-strength steels
» ER70S-6 / W3Si1 classification provides a widely used filler composition for general steel fabrication and repair
» Elevated manganese and silicon content provides effective deoxidation during welding and improves tolerance to minor surface contamination
» Copper-coated surface helps protect the rods during storage and supports consistent handling
» 2.4mm diameter provides a versatile filler size for a wide range of TIG welding applications
» 1000mm straight rod format is suitable for manual GTAW / TIG welding
» Designed for use with pure Argon shielding gas for stable TIG welding performance
» Typical deposited weld metal provides 470MPa yield strength and 560MPa tensile strength
» Impact toughness of approximately 70J at -30°C supports applications requiring good low-temperature mechanical performance
» Suitable for structural steel fabrication, pipework, machinery repairs, sheet metal and general engineering applications
Technical Specifications
» Brand: ESAB / Filarc
» Product Range: PZ6500
» Part Number: 203624R150
» Product Type: TIG Welding Rods
» Material: Carbon-Manganese Steel
» Grade: A18 / ER70S-6 / W3Si1
» Rod Diameter: 2.4mm
» Rod Length: 1000mm
» Pack Weight: 5kg
» Surface Finish: Copper-Coated
» Welding Process: GTAW / TIG
» Recommended Shielding Gas: Pure Argon (I1)
» Carbon Content: 0.078%
» Manganese Content: 1.46%
» Silicon Content: 0.85%
» Yield Strength: 470MPa
» Tensile Strength: 560MPa
» Elongation: 26%
» Impact Toughness: 70J At -30°C
» AWS Classification: AWS A5.18 ER70S-6
» EN ISO Classification: EN ISO 636-A W 42 3 W3Si1
» Application: TIG Welding Of Mild And Medium-Strength Steels
