Electrode Holder 400A Screw Type EW400T
SKU:
10024346
The Weldfast / Weldability SIF EW400T 400A Twist-Grip Electrode Holder is a heavy-duty screw-type holder designed to provide secure electrode clamping and efficient current transfer during MMA welding. Featuring an insulated yellow handle, brass internal contact assembly and capacity for electrodes from 1.6mm to 5.0mm, it is suitable for demanding workshop, fabrication and site welding applications.
Features & Benefits
» Heavy-duty twist-grip electrode holder designed for professional MMA welding applications
» Screw-type locking mechanism provides a firm and secure grip on the welding electrode
» Adjustable electrode positioning allows the rod to be held securely at the required working angle
» Rated up to 400A at a 35% duty cycle for demanding welding operations
» Accommodates electrodes from 1.6mm to 5.0mm, including commonly used 2.5mm, 3.2mm and 4.0mm sizes
» High-conductivity brass internal contact assembly supports efficient transfer of welding current
» Fully insulated, heat-resistant handle helps isolate the operator from the electrically conductive components
» High-visibility yellow handle makes the holder easy to identify amongst welding equipment
» Internal grub-screw cable connection provides secure termination of welding cable
» Accepts welding cable up to 50mm² for compatibility with heavy-duty MMA welding leads
» Suitable for fabrication, structural steelwork, maintenance, repair and general workshop welding
Technical Specifications
» Brand: Weldfast / Weldability SIF
» Product Code: EW400T
» Product Type: Twist-Grip Electrode Holder
» Welding Process: MMA / Stick Welding
» Maximum Current Rating: 400A
» Duty Cycle: 35% At 400A
» Current Rating At 60% Duty Cycle: 300A
» Electrode Diameter Range: 1.6–5.0mm
» Maximum Jaw Opening: 5mm
» Maximum Cable Size: 50mm²
» Cable Connection: Dual Grub Screw
» Overall Length: 225mm
» Grip Length: 170mm
» Handle Diameter: 35mm
» Approximate Weight: 0.46kg
» Internal Contact Material: Brass
» Handle Type: Fully Insulated
» Handle Colour: Yellow
» Electrode Retention: Screw / Twist-Grip
» Application: MMA Welding Electrode Holding And Current Transfer
