Electrode Hilco Basic 55 7016 3.2mm x 450mm 5.3Kg
SKU:
10111180
The Weldgas WER 3509 Hilco Basic 55 3.2mm MMA Welding Electrodes are double-coated basic-rutile electrodes designed to combine low-hydrogen weld metal with stable arc characteristics and straightforward handling. Supplied as 3.2mm x 450mm electrodes in a 5.3kg box, they are suitable for structural steelwork, pipe welding and general industrial fabrication.
In Stock
Typical Lead Time: 12 Days
Features & Benefits
» Double-coated basic-rutile MMA electrode combining the mechanical properties of a basic electrode with smooth welding characteristics
» Low-hydrogen weld deposit with an H10 classification for controlled diffusible hydrogen levels
» Stable arc characteristics provide good control during root, fill and cap passes
» Suitable for AC and DC welding power sources, providing flexibility across workshop and site equipment
» 3.2mm electrode diameter provides a versatile balance between deposition rate and weld pool control
» Suitable for all standard welding positions except vertical down
» Good slag detachability assists cleaning between passes and improves productivity
» Mechanical properties provide a minimum yield strength above 420MPa and tensile strength of 500–640MPa
» Impact toughness suitable for applications requiring performance at temperatures down to -30°C
» Suitable for unalloyed structural steels and compatible boiler and pressure vessel steels
» Ideal for structural fabrication, pipework, shipbuilding, bridges, storage tanks and general industrial welding
Technical Specifications
» Brand: Hilco
» Distributor: Weldgas
» Product Range: Basic 55
» Product Code: WER 3509
» Product Type: MMA Welding Electrode
» Coating Type: Double-Coated Basic-Rutile
» Electrode Diameter: 3.2mm
» Electrode Length: 450mm
» Box Weight: 5.3kg
» AWS Classification: AWS A5.1 E7016
» EN ISO Classification: EN ISO 2560-A E 38 3 B 12 H10
» Diffusible Hydrogen Classification: H10
» Recommended Current Range: 90–140A
» Current Type: AC / DC
» Welding Positions: All Positions Except Vertical Down
» Yield Strength: >420MPa
» Tensile Strength: 500–640MPa
» Elongation: >22%
» Impact Toughness Temperature: Down To -30°C
» Application: Structural Steelwork, Pipe Welding, Shipbuilding, Bridges, Storage Tanks And Industrial Fabrication
