Electrode Hilco Basic 55 7016 4.0mm x 450mm 5.2Kg
SKU:
10111205
The Weldgas WER3510 Hilco Basic 55 4.0mm MMA Welding Electrodes are double-coated basic-rutile electrodes designed to combine low-hydrogen weld metal with stable arc characteristics and smooth weld pool control. Supplied as 4.0mm x 450mm electrodes in a 5.2kg box, they are particularly suited to heavy fill and cap passes, structural steelwork and demanding industrial fabrication.
Features & Benefits
» Double-coated basic-rutile MMA electrode combining the mechanical properties of a basic electrode with smooth welding characteristics
» Low-hydrogen weld deposit with an H10 classification for controlled diffusible hydrogen levels
» Stable arc characteristics and controlled weld pool support consistent welding on demanding structural applications
» 4.0mm diameter provides increased deposition for fill and cap passes on thicker sections and larger joints
» Suitable for AC and DC welding power sources for flexibility across workshop and site equipment
» Suitable for all standard welding positions except vertical down
» Good slag detachability assists cleaning between passes and supports efficient multi-pass welding
» Mechanical properties provide a minimum yield strength above 420MPa and tensile strength of 500–640MPa
» Impact toughness suitable for applications requiring performance at temperatures down to -30°C
» Suitable for unalloyed structural steels and compatible boiler and pressure vessel steels
» Ideal for structural steelwork, heavy fabrication, machinery repair, bridge construction and shipbuilding
Technical Specifications
» Brand: Hilco
» Distributor: Weldgas
» Product Range: Basic 55
» Product Code: WER3510
» Product Type: MMA Welding Electrode
» Coating Type: Double-Coated Basic-Rutile
» Electrode Diameter: 4.0mm
» Electrode Length: 450mm
» Box Weight: 5.2kg
» AWS Classification: AWS A5.1 E7016
» EN ISO Classification: EN ISO 2560-A E 38 3 B 12 H10
» Diffusible Hydrogen Classification: H10
» Recommended Current Range: 140–190A
» Current Type: AC / DC
» Welding Positions: All Positions Except Vertical Down
» Yield Strength: >420MPa
» Tensile Strength: 500–640MPa
» Elongation: >22%
» Impact Toughness Temperature: Down To -30°C
» Application: Heavy Fill And Cap Passes, Structural Steelwork, Heavy Fabrication, Machinery Repair, Bridge Construction And Shipbuilding
