Gouging Torch K3 600A MMA2025
SKU:
10024386
The Weldfast MMA2025 K3 600A Carbon Arc Air Gouging Torch is a heavy-duty straight-head torch designed for controlled metal removal, weld defect removal and joint preparation. Rated up to 600A and supplied with a 6ft monocable assembly, it uses compressed air and carbon electrodes to remove molten metal efficiently in demanding fabrication, repair and maintenance applications.
Features & Benefits
» Heavy-duty K3-style carbon arc air gouging torch designed for demanding fabrication, repair and maintenance work
» Rated up to 600A for medium-to-heavy industrial gouging applications
» Uses an electric arc to melt the workpiece while compressed air removes the molten metal from the gouge
» Suitable for removing defective weld metal, back gouging, joint preparation and general metal removal
» Straight-head configuration provides straightforward positioning and control during gouging operations
» Accepts round carbon electrodes from 3.2mm to 9.5mm for versatility across different gouge sizes
» Compatible with flat gouging electrodes up to approximately 10mm
» Requires a minimum compressed air pressure of approximately 5.6 bar for effective molten metal removal
» 360° adjustable electrode positioning allows the carbon to be set to suit different working angles
» Supplied with a heavy-duty 6ft monocable assembly combining the electrical and compressed air supply
» Protective cable sheathing helps resist heat, sparks, molten slag and abrasion in demanding working environments
» Suitable for fabrication, weld repair, maintenance, foundry work and structural steel applications
Technical Specifications
» Brand: Weldfast
» Product Code: MMA2025
» Product Type: Carbon Arc Air Gouging Torch
» Torch Style: K3 / ArcAir-Style
» Head Configuration: Straight
» Maximum Current Rating: 600A
» Minimum Air Pressure: 80psi (Approximately 5.6 Bar)
» Air Flow Requirement: 22–28cfm (Approximately 624–792 L/min)
» Round Electrode Diameter Range: 3.2–9.5mm
» Flat Electrode Capacity: Up To Approximately 10mm
» Electrode Adjustment: 360°
» Cable Type: Monocable
» Cable Length: 6ft (Approximately 1.8m)
» Application: Carbon Arc Gouging, Weld Removal, Back Gouging, Defect Repair And Joint Preparation
