Spanner Comb Ratchet Rev 24mm 7UR 2297396 Gedore
SKU:
10077904
The Gedore 2297396 Reversible Combination Ratchet Spanner 24mm is a professional-grade ratcheting wrench designed for high-torque fastening in confined spaces. It highlights a reversible fine-tooth ratchet mechanism, UD profile ring, and premium chrome-plated vanadium steel construction for demanding industrial and automotive applications.
In Stock
Typical Lead Time: 14 Days
Email a Friend
Stock Notice
Not enough Inventory? Submit your email address and desired total quantity below, and we will notify you when stock arrives.
Features & Benefits
» Professional reversible combination ratchet spanner with identical 24mm openings at both ends
» Fine-tooth ratchet mechanism requires only a 6° working angle for fast operation in restricted spaces
» Lever-operated reversing mechanism allows quick direction changes without removing the spanner
» UD profile ring delivers high torque transfer while reducing the risk of fastener damage
» 13° offset ring provides improved clearance around surrounding components
» Hollow-profile handle offers a comfortable grip while maintaining excellent strength
» Warp-resistant double T-girder shaft design provides exceptional rigidity under heavy loads
» Manufactured from premium Gedore 31CrV3 vanadium steel for outstanding durability and long service life
» Matt chrome-plated finish reduces glare while providing excellent corrosion resistance
» Locking insert and ratchet pawl feature a manganese phosphate finish for enhanced wear resistance
» Hot-forged and precision ground for professional performance and accuracy
» Compatible with Gedore 7 RA and 7 RB adaptors (available separately) for use as a bit ratchet
» Ideal for automotive, engineering, plant maintenance, manufacturing, and industrial applications
Technical Specifications
» Brand: Gedore
» Series: 7UR 24
» Product Code: 2297396
» Product Type: Reversible Combination Ratchet Spanner
» Spanner Size: 24mm
» Material: Gedore 31CrV3 Vanadium Steel
» Manufacturing Process: Hot Forged
» Finish: Matt Chrome Plated
» Ring Profile: UD Profile
» Ratchet Direction: Reversible With Lever Change
» Ring Offset: 13°
» Working Angle: 6°
» Overall Length: 325mm
» Open End Head Width: 48.0mm
» Ring End Head Width: 52.5mm
» Open End Head Height: 13.3mm
» Ring End Head Height: 7.9mm
» Weight: 0.449kg
» Compatible Accessories: Gedore 7 RA And 7 RB Adaptors (Sold Separately)
» Suitable Applications: Automotive, Industrial Maintenance, Engineering, Manufacturing, Plant Maintenance, And Mechanical Assembly
