Hose Tail Hex 1"BSPT x 1" Stainless
SKU:
10014061
The SJ-F29-16 Hose Tail Adaptor is a heavy-duty brass fitting designed for connecting flexible hose to BSP threaded systems. It highlights a tapered BSPT male thread for secure sealing, a robust 1in hose barb connection, and dependable performance in fluid transfer applications.
Features & Benefits
» Heavy-duty hose tail adaptor designed for connecting flexible hose to threaded pipe systems
» 1in BSPT male tapered thread provides a tight and leak-resistant mechanical seal
» 1in hose barb designed to suit 1in (25.4mm) internal diameter flexible hose
» Suitable for fluid transfer, irrigation, pneumatic, and industrial hose applications
» Hose barb profile provides secure hose retention when used with suitable clamps
» Compatible with BSP threaded ports including BSPT and BSPP female connections
» Recommended for use with PTFE tape or pipe sealant compound during installation
» Heavy-duty hose clamps or bolt clamps should be fitted to prevent hose blow-off under pressure
» Robust fitting design supports dependable long-term performance in demanding environments
» Suitable for workshop, agricultural, industrial, and maintenance installations
» Not compatible with American NPT threaded systems
Technical Specifications
» Product Type: Hosetail Adaptor
» Part Number: SJ-F29-16
» Connection A: 1 in Male BSPT (British Standard Pipe Taper)
» Connection B: 1 in Hose Barb
» Hose Compatibility: 1 in / 25.4 mm Internal Diameter Hose
» Thread Type: BSPT Tapered Male Thread
» Construction: Straight Hose Tail Adaptor Design
» Sealing Method: Tapered Thread Provides Leak Proof Mechanical Seal
» Installation Requirement: Apply PTFE Tape Or Pipe Sealant To BSPT Threads
» Hose Securing Method: Use Heavy Duty Worm Drive Or Bolt Clamp
» Thread Compatibility: Suitable For BSPT And BSPP Female Ports
» Thread Restriction: Not Compatible With NPT Threads
» Application: Fluid Transfer And Pneumatic Systems
» Suitable Use: Industrial, Commercial And Workshop Installations
