Coupling Camlock `C` 1" Tail Polyprop
SKU:
10014344
The PARKAIR Polypropylene Cam & Groove Type C Female Coupler x Hose Shank AH-C100-P is a lightweight quick-connect hose coupling designed for efficient low-pressure fluid transfer applications. It highlights durable polypropylene construction, excellent chemical resistance, and a secure hose tail connection for dependable industrial performance.
Features & Benefits
» Type C cam and groove coupling with female coupler and integrated hose shank connection
» Manufactured from polypropylene for lightweight performance and excellent chemical resistance
» Female camlock lever arms provide quick and secure connection to compatible male adaptors
» Multi-barbed hose tail design improves hose retention when installed with suitable clamps
» Resistant to acids, agricultural chemicals, and corrosive fluid environments
» Lightweight construction reduces strain on hose assemblies and improves handling
» Maximum working pressure of 7 bar (approximately 100 PSI) under ambient conditions
» Designed for low-pressure liquid transfer and industrial fluid handling
» Ideal for agricultural, chemical processing, water transfer, and washdown applications
» Compatible with standard cam and groove coupling systems
» Cost-effective alternative to metal couplings where corrosion resistance is required
Technical Specifications
» Product Name: PARKAIR Polypropylene Cam & Groove Coupler
» Part Number: AH-C100-P
» Product Type: Type C Female Coupler x Hose Shank
» Brand: PARKAIR
» Distribution Source: Tom Parker Ltd
» Material: Polypropylene
» Coupling Configuration: Female Camlock Coupler To Hose Tail
» Size: 1 in
» Hose Compatibility: 1 in / 25 mm Internal Diameter Hose
» Maximum Working Pressure: 7 Bar
» Maximum Working Pressure Imperial: Approx. 100 Psi
» Connection Type: Female Lever Locking Cam Arms
» Hose Connection Type: Multi Barbed Hose Shank
» Chemical Resistance: Resistant To Acids, Agricultural Chemicals And Corrosive Fluids
» Construction Feature: Lightweight Corrosion Resistant Design
» Application: Fluid Transfer And Industrial Hose Connections
» Suitable Media: Industrial Fluids And Agricultural Chemicals
» Usage Limitation: Lower Pressure Rating Compared With Aluminium And Stainless Steel Variants
