Circular Saw 165mm 18v B/L B/O XR DCS565N-XJ
SKU:
10127694
Brand:
DEWALT
The DeWALT DCS565N-XJ 18V XR Brushless 165mm Circular Saw Body Only delivers fast, accurate and consistent cutting across a variety of applications. Its brushless motor provides speeds up to 4,950 rpm, while tool-free depth and bevel adjustments allow a maximum 55mm cutting depth at 90° and bevel capacity up to 50°. A bright LED improves cut-line visibility, with AIRLOCK compatibility supporting connection to DeWALT dust extractors for cleaner working.
Product Overview
The DeWALT DCS565N-XJ is an 18V XR cordless circular saw powered by an efficient brushless motor delivering up to 4,950 rpm. Designed around a 165mm blade, it provides a maximum 55mm cutting depth at 90° and bevel capacity up to 50°. Tool-free adjustments, LED illumination and an aluminium shoe support accurate, convenient cutting across varied applications.
Features & Benefits
» 18V XR brushless motor provides enhanced efficiency and durability for demanding cutting applications
» Maximum speed of 4,950 rpm supports fast, accurate and consistent cutting
» 165mm blade provides a maximum cutting depth of 55mm at 90°
» Bevel capacity up to 50° provides flexibility for angled cutting applications
» Tool-free depth and bevel adjustments allow quick and convenient setup between cuts
» Bright integrated LED improves cut-line visibility for greater accuracy while working
» Aluminium shoe combines reduced weight with high durability
» Lock-off switch and electronic motor brake provide additional control and work safety
» Direct AIRLOCK compatibility enables easy connection to compatible DeWALT dust extractors
» Part of the cordless 18V XR system and compatible with more than 250 solutions
Technical Specifications
» Product Type: Circular Saw
» Model: DCS565N-XJ
» Product Range: XR
» Voltage: 18V
» Cordless Or Corded: Cordless
» Power Source: Battery
» Tool Only: Yes
» Motor Type: Brushless
» Total Number Of Batteries: 0
» Charger Included: No
» Maximum Speed: 4,950 rpm
» Blade Diameter: 165mm
» Maximum Depth Of Cut At 90°: 55mm
» Maximum Bevel Capacity: 50°
» Dust Collection: Yes
» Dust Extraction Compatibility: DeWALT AIRLOCK System
» Shoe Material: Aluminium
» Included Saw Blade: 165mm 24-Tooth TCT Saw Blade
» Included Accessories: Hex Key, Rip Fence And Dust Extraction Port
